1. Core Technical Parameters

Supply Voltage：24 VDC

I/O Channel：8AI+8AO

Analog Range：4~20mA, 0~10VDC

Conversion Precision：12 bit

Dielectric Isolation：1500 VAC

Working Temperature：-10℃ ~ +60℃

Installation Standard：DIN rail mount

2. Compatibility & Expandability

Same-brand Compatibility

ABB DAI01 fits the ABB Freelance DCS system rack structure. Field automation technicians fix multiple ABB DAI01 on rack backboard to raise analog signal collection capacity during workshop transformation. ABB DAI01 locks into standard card slots and connects ABB main controller and base terminal modules without extra transition accessories. Manual dial setting on module surface lets ABB DAI01 match original ABB field transmitters deployed in industrial sites.

Cross-brand Compatibility

Proprietary rack bus design forbids direct wiring connection of ABB DAI01 with non-ABB control hardware. External protocol conversion equipment becomes necessary to link ABB DAI01 to PLC products manufactured by Siemens or Schneider. Common industrial analog signal specifications support ABB DAI01 to access various third-party two-wire sensors with no internal circuit refitting.

3. Lifecycle Cost Analysis

Service cycle of ABB DAI01 is defined as 10 years, exchange rate:1USD=7.2CNY, purchase and installation expenses are excluded

Annual routine maintenance cost: Routine function inspection and dust removal for ABB DAI01 costs 28 USD per year, total 10-year maintenance expense: 280 USD

Spare part replacement cost: Core circuit failure of ABB DAI01 appears about once every 8 years, single spare part price:370 USD, total replacement cost within 10 years:370 USD

Retrofit expense saving: Original on-site wiring keeps usable for ABB DAI01 during cabinet renovation, cutting redundant construction cost by 215 USD compared with mismatched alternative parts

Total cumulative operating cost for single ABB DAI01 in ten years: 435 USD
