1. Core Technical Parameters

Supply Voltage：24 VDC

Analog Input：8 channels

Input Signal：4~20mA, Pt100 thermal signal

Resolution：15 bit

Galvanic Isolation：2000 VAC

Ambient Range：-20℃ ~ +65℃

Installation：DIN rail mounting

2. Compatibility & Expandability

Same-brand Compatibility

ABB AI830A fits the full AC800M DCS rack series from ABB. On-site maintenance personnel arrange multiple ABB AI830A on cabinet backplane to enrich analog signal collection points for production upgrades. ABB AI830A inserts standard card slots and establishes direct connection with ABB base unit and CPU modules without extra transition terminals. Manual address coding on the module allows ABB AI830A to match various original ABB temperature transmitters deployed on industrial sites.

Cross-brand Compatibility

Proprietary internal bus design prevents direct hardware docking of ABB AI830A with controllers made by other brands. Independent protocol gateway becomes essential to connect ABB AI830A to Siemens or Schneider automation hardware. Globally unified thermal and current signal standards let ABB AI830A pair with third-party temperature sensors with no internal circuit modification.

3. Lifecycle Cost Analysis

Service cycle of ABB AI830A lasts 10 years, exchange rate:1USD=7.2CNY, purchase and installation fees are excluded from accounting

Annual routine maintenance cost: Periodic function test and dust cleaning for ABB AI830A costs 29 USD per year, total 10-year maintenance expense: 290 USD

Spare part replacement cost: Key component damage of ABB AI830A generally happens once every 7 years, single spare part price: 382 USD, total replacement expense within 10 years: 382 USD

Retrofit expense saving: Original field wiring remains usable for ABB AI830A during cabinet reconstruction, saving 226 USD extra construction cost compared with mismatched alternative modules

Total cumulative operating cost for single ABB AI830A across ten service years: 446 USD
