1. Core Technical Parameters

Supply Voltage：24 VDC

AI Channel：8 channels

Input Signal：4~20mA, 0~10VDC

Resolution：16 bit

Channel Isolation：2500 VAC

Operating Temperature：-20℃ ~ +70℃

Mounting Standard：DIN rail

2. Compatibility & Expandability

Same-brand Compatibility

ABB AI845 matches ABB AC800M DCS rack system. Site technicians install multiple ABB AI845 on system backplane to expand analog collecting points during facility reform. ABB AI845 plugs into standard rack slots and connects directly with ABB CPU and related base modules without auxiliary adapters. Dial code setup on module surface helps ABB AI845 coordinate with original ABB field sensors on production sites.

Cross-brand Compatibility

DCS exclusive bus structure blocks direct hardware connection of ABB AI845 to non-ABB control units. Additional protocol conversion modules are required to link ABB AI845 with PLC products from Siemens and Schneider. Global universal analog signal criteria allow ABB AI845 to access most third-party industrial transmitters with no inner circuit change.

3. Lifecycle Cost Analysis

Service cycle of ABB AI845 covers 10 years, exchange rate:1USD=7.2CNY, purchase and installation fees get removed from calculation

Annual routine maintenance cost: Regular circuit check and dust removal for ABB AI845 costs 30 USD per year, total ten-year maintenance cost:300 USD

Spare part replacement cost: Core part overhaul of ABB AI845 occurs once every 7 years, single spare part price:395 USD, total replacement cost within 10 years:395 USD

Retrofit expense saving: Original wiring stays available for ABB AI845 during cabinet upgrading, cutting extra construction cost by 238 USD against incompatible substitute parts

Total cumulative operating cost for single ABB AI845 over 10 years: 457 USD
