GE Fanuc IC695PNS001: PROFINET Scanner Module for PACSystems RX3i PLC Systems

Product Overview

The GE Fanuc IC695PNS001 is a high-performance PROFINET Scanner (PNS) module designed for PACSystems RX3i PLC systems, engineered to enable seamless integration of remote RX3i I/O racks with PROFINET IO-Controllers in industrial automation environments. This IC695PNS001 features 4 Ethernet ports supporting 10/100/1000Mbps transmission rates and a USB micro port for firmware upgrades, enabling efficient data exchange between the PLC and PROFINET devices. As a key component of the RX3i hardware lineup, the IC695PNS001 boasts robust protocol compatibility, advanced diagnostic features, and reliable performance, making it ideal for industrial automation, process control, and manufacturing monitoring applications requiring PROFINET connectivity. Its compact single-slot design simplifies integration into existing RX3i racks, with flexible configuration options to streamline setup and ensure stable operation in harsh industrial environments.

Key Technical Specifications

• Part Number: IC695PNS001 | Product Family: PACSystems RX3i PROFINET Scanner Modules

• Port Configuration: 4 Ethernet ports (10/100/1000Mbps) + 1 USB micro port for firmware upgrades, supporting flexible device connectivity

• Protocol Compatibility: Fully compliant with PROFINET IO standards, enabling seamless communication with PROFINET IO-Controllers and I/O devices

• Device Capacity: Supports up to 128 PROFINET I/O devices, enabling large-scale industrial network configuration

• Functional Features: SD card-based configuration transfer, simplified setup via Proficy Machine Edition (v8.0 or higher), and comprehensive LED status indicators for easy monitoring

• Physical & Environmental: IP20 protection rating, compatible with RX3i backplanes, operating temperature range of -10℃ to +60℃, suitable for harsh industrial conditions

• Power Consumption: 1.2A @ 3.3VDC or 1.1A @ 5VDC from the PLC backplane, with efficient power management for long-term operation

Core Selling Points

The GE Fanuc IC695PNS001 stands out for its dedicated PROFINET scanning capability, enabling seamless integration of remote RX3i I/O racks with PROFINET IO-Controllers to expand industrial network coverage. Its 4 high-speed Ethernet ports and USB micro port provide flexible connectivity options, supporting efficient data exchange and convenient firmware upgrades. The IC695PNS001’s SD card-based configuration transfer simplifies setup and maintenance, reducing reliance on software tools and minimizing downtime. Its robust protocol compliance and advanced diagnostic features ensure stable and reliable communication even in noisy industrial environments.

Practical Application Highlights

The IC695PNS001 delivers consistent performance and flexible adaptability for industrial automation systems, making it a preferred choice for engineers and system integrators. Its wide compatibility with PROFINET devices and RX3i I/O modules simplifies system integration and expansion. The IC695PNS001’s built-in diagnostic features (LED indicators) enable quick fault localization and resolution, boosting maintenance efficiency. It is widely used in industrial automation, process control, and manufacturing monitoring systems, serving as a dependable PROFINET Scanner solution for PACSystems RX3i PLC systems.
