1. Core Technical Specifications

Communication Protocol：PROFIBUS DP-V1 Master/Slave Supported Baud Rate：9.6 kbit/s to 12 Mbit/s Port Configuration：1 isolated 9-pin D-sub PROFIBUS port Galvanic Isolation Rating：2500 VAC channel-to-bus Compatible I/O Platform：ABB S800 distributed I/O system Operating Ambient Temperature：-20 °C ~ +70 °C Typical Power Consumption：3.3 W Mounting Standard：S800 backplane + TS35 DIN rail

2. Regional Deployment & Field Project Applications

ABB CI854AK01 3BSE030220R1 delivers stable fieldbus connection for process control projects across Middle East oil & gas extraction sites. Harsh desert temperatures and high dust levels do not disrupt signal transmission of the module in onshore wellhead control cabinets. The module meets regional hazardous area electrical installation specifications. ABB CI854AK01 3BSE030220R1 also serves as core communication node for European discrete manufacturing production lines, including automotive assembly and food packaging workshops. The module matches existing PROFIBUS network infrastructure of local factories and cuts on-site network reconstruction workload. Southeast Asian water treatment plants and thermal power stations deploy the module for distributed I/O signal aggregation, with full compliance to local industrial electrical safety codes.

3. Compatibility & Expansion Performance

Same-brand Ecosystem Matching

ABB CI854AK01 3BSE030220R1 natively docks with all S800 series I/O modules and AC800M series CPU controllers. Field engineers mount the module on standard S800 backplanes to expand PROFIBUS master station capacity for multi-node control systems. The module supports direct configuration via ABB Control Builder M software, with no extra driver installation required.

Cross-brand Network Interoperability

Standard PROFIBUS DP-V1 protocol allows ABB CI854AK01 3BSE030220R1 to connect with third-party PLC systems including Siemens S7 series and Schneider Quantum series. No additional protocol conversion gateway is required for basic cyclic data exchange between the module and non-ABB master stations. Universal D-sub port design fits standard PROFIBUS cable connectors from all mainstream industrial brands.
