1. Core Technical Parameters

Supply Voltage：24 VDC

Communication Interface：RS485 Modbus RTU

Max Station Count：31 slave nodes

Transmission Rate：1200–115200 bit/s

Galvanic Isolation：2000 VAC

Operating Temperature：-20℃ ~ +70℃

Rack Carrier：AC800 control backplane

2. Compatibility & Expandability

Same-brand Compatibility

ABB CI545V01 is a Modbus communication interface module tailored for ABB AC800 control platform. Site automation technicians install multiple ABB CI545V01 on cabinet backplanes to build multi-channel serial bus networks for factory auxiliary equipment monitoring. ABB CI545V01 slides into standard single rack slots and exchanges real-time parameter data with ABB PM800 series CPU and S800 distributed I/O without extra signal transfer terminal boards. Surface coding switches support offline address configuration to maintain stable cyclic data transmission between ABB CI545V01 and all ABB field-mounted frequency converters and measuring transmitters.

Cross-brand Compatibility

Exclusive AC800 internal backplane bus architecture stops direct hardware interconnection of ABB CI545V01 to third-party main controllers. Separate protocol transition gateways are required to construct data links connecting ABB CI545V01 with Siemens and Schneider PLC equipment. General Modbus RTU industrial standard allows ABB CI545V01 to collect operating feedback signals from most aftermarket field instruments, no internal circuit reconstruction required.

3. Lifecycle Cost Analysis

Service cycle of ABB CI545V01 covers 10 years, exchange rate:1USD=7.2CNY, purchase and installation expenses are excluded from all cost statistics

Annual routine maintenance cost: Serial port signal calibration and internal dust clearance for ABB CI545V01 costs 34 USD per year, total 10-year maintenance expense: 340 USD

Spare part replacement cost: Modbus transceiver chip damage of ABB CI545V01 generally occurs once every 7 years, single spare module price: 442 USD, total replacement expense within 10 years: 442 USD

Retrofit expense saving: Original cabinet wiring layout fully fits ABB CI545V01 during control system upgrade projects, saving 278 USD extra construction labor cost compared with incompatible substitute serial communication modules

Total cumulative running cost for single ABB CI545V01 across ten service years: 504 USD
